Tenda

Tenda AC23 GAMER Dual Band AC2100 Wifi Router - Networks

Tenda AC23 GAMER Dual Band AC2100 Wifi Router - Networks

Regular price $142.00 USD
Regular price $150.00 USD Sale price $142.00 USD
Sale Sold out
Shipping calculated at checkout.

TENDA Router AC23 / Dual Band Gigabit WiFi Router

AC23 is a gigabit dual-band wireless router specially designed for homes with high-speed Internet access. It supports 802.11ac wave2 technology and provides WiFi speed up to 2033Mbps (2.4GHz: 300Mbps, 5GHz: 1733Mbps) to achieve the best performance for your fiber internet connection. Powered by 5GHz band 4X4 MU-MIMO technology, it provides wider WiFi coverage and faster WiFi speed than normal routers with 3X3 MU-MIMO technology. Equipped with full gigabit ports, it supports bandwidth access of up to 1000Mbps. 28nm 1GHz CPU equipped with 500MHz coprocessor, dual-core design delivers faster processing speed and provides optimized operation. Featured with 7*6dBi external antennas, AC23 outperforms in performance and wall penetration ability.

AC2100 High Speed ​​WiFi

AC23 is a dual-band gigabit wireless router, adopted with 802.11 ac wave2 technology and provides speed up to 2033 Mbps to make the most of your gigabit fiber internet.


4x4 MU-MIMO for 5 GHz band

Powered by 5GHz band 4X4 MU-MIMO technology, it provides wider WiFi coverage and faster WiFi speed than normal routers with 3X3 MU-MIMO technology.


Built-in signal amplifier for main chip

The built-in signal booster is used in AC23's 2.4GHz and 5GHz bands to improve penetration capacity and expand WiFi coverage.


7*6dBi External Antennas for Better WiFi Signal

With 7*6 dBi external antennas and four 5Ghz band data streams, the AC23 can provide optimized WiFi coverage and better 5GHz WiFi signal.


Supports fiber Internet up to 1000Mbps

Equipped with full gigabit ports, it supports bandwidth access of up to 1000 Mbps.


Dual-core design provides more stable operation

1GHz 28nm CPU equipped with 500MHz coprocessor, dual-core design along with ethernet process brings faster processing speed and provides optimized operation.


Supports IPv6 protocol

AC23 supports IPv6, can reduce data transmission time and minimize delay, provide better gaming experience.


Other features

Store
Broadband account migration without any configuration
Store
Beamforming + Support
Store
Unifies 2.4GHz and 5GHz signals
Store
Guest Network
Store
Client filter support


EIRP Power (Max.)

2.400-2.4835GHz:19.86dBm (EIRP)
5.150-5.250GHz:22.96dBm (EIRP)

Standard and protocol

IEEE802.3, IEEE802.3u,IEEE802.3ab

Interface
1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports
Antenna
7*6dBi external antennas
Buttons
1*WPS/Reset button

Power
Input:AC 100-240V~50/60Hz 0.6A
Output:DC 12V1.5A
Dimensions
238.9*144.3*40.3mm
LED
Sys*1,WAN*1, LAN*1,WiFi/WPS*1
Wireless standard
IEEE 802.11ac wave2/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz

Speed
5GHz: Up to 1733Mbps
2.4GHz: Up to 300Mbps

Frequency
Simultaneous dual band 2.4 & 5GHz

Potency of transmission
EC:
<20dBm(2.4G)
<23dBm(5G)
FCC:
<30dBm

Basic characteristics
SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
MU-MIMO
Wireless security
WPA-PSK/WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS (WiFi Protected Set-up) fast encryption
Internet connection type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating mode
Wireless Router Mode
Universal Repeater Mode
WISP Mode
DHCP server
DHCP Server
DHCP Client List
DHCP Reservation

virtual server
Port Forwarding
DMZ Host
UPnP

Security
Client Filter
Parental Control (support black list and white list)
Remote Web Management
Firewall
Forbid UDP flood attack
Forbid TCP flood attack
Forbidden flood attack
Forbid WAN PING from internet
DDNS
Support DynDNS, Oray.com, 88ip
VPN
IPsec pass through
PPTP pass through
L2TP pass through
PPTP server
PPTP client
L2TP client
Special Features
Smart Traffic Prioritization
PPPoE Username/password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED on/off
Tenda Cloud
Tenda App

Others
Bandwidth Control
IPTV
MAC Clone
Static Routing
System Log
Backup & Restore configurations
Firmware upgrade online
Firmware upgradeable via browser
Supports IPv6
Temperature
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.
Humidity
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Default settings
Default Access: tendawifi.com
Certifications
CE/FCC/RoHS
Package content
Wireless Router*1
Power Adapter *1
Install Guide*1
Ethernet Cable*1
